Product Details
- Smart-Vue Pro Duo Remote Monitoring System with two sensor channels enables simultaneous monitoring of multiple equipment ideal for use in compliant labs
- LoRaWAN (Long Range wireless Area Network) a stand-alone dedicated network with a connectivity range up to 9 km
- • Compliance: 21 CFR Part 11 guidelines, cGxP and SOP
- Compatible with Thermo Fisher Scientific Refrigerators, Freezers and multiple other brands
- • Includes: two 3.6 V lithium batteries, one sensor mounting kit, one mounting holder, one antenna and one 5-foot flat cable
- Instant alerts enable proactive response before out-of-range samples are compromised
- Remote monitoring ideal for compliant labs: automatic and continuous data logging for a permanent audit trail
- Supports asset/cost optimization by preventing replacement of samples and equipment
- LoRaWan Network features:
- LoRa (Long Range) technology enables scalability with single gateway enabling coverage of large areas; eliminates the need for repeaters
- Each gateway supports up to 300 data-logging parameters
- Dedicated wireless network
- Setup requires minimal IT support
- Gateway pushes data to cloud via a local network connection (Ethernet or Wi-Fi)
- Supports sample protection, compliance and asset/cost optimization
- Bright 2.4” color touchscreen LCD display features:
- Enables multiple viewing of multiple sensors simultaneously
- Battery, wireless signal name
- Red-light diffuser alarm
- Easy-to-see key information and status
- Audio/visual alarms for local notification
- Low AC power consumption via USB port access
- Automatic sensor detection (choice of wired or wireless)
- Allows direct connection via 4–20 mA output
- Lab Monitoring:
- Ambient monitoring: Temperature with external sensor; temperature and relative humidity (RH) with external sensor
- Ultra low-temperature freezers –100°C to +150°C
- Auto-cascade ultra low-temperature freezers –155°C to –100°C
- Thermo Scientific™ LN2 Phase Separator/CryoPlus™ Storage Systems –196°C to –100°C
- Refrigerators (single-, double-, and triple-door) 0°C to +10°C
- Freezers –40°C to 0°C
- Refrigerator-freezer combinations per chamber (i.e., top/bottom, left/right) –30°C to +8°C
- Cold rooms –30°C to +8°C; –40°C or colder
- Incubators Ambient to +100°C, +120°C; and relative humidity (RH): 0–99.9%, non-condensing
- Water baths Ambient to +120°C
- 4–20 mA current loop (0–5 V and 0–10 V) 4–20 mA; device with a 4–20 mA self-powered output
- Gateway options
- Smart-Vue Pro LoRaWAN 915 (#SVPHWRLGW001): 915 MHz LoRaWAN platform–enabled Ethernet/Wi-Fi connectivity
- receiver with universal power supply
- Smart-Vue Pro LoRaWAN 865-868 (#SVPHWRLGW002): 865–868 MHz LoRaWAN platform–enabled Ethernet/Wi-Fi connectivity receiver with universal power supply
- Accessories:
- Wireless Data logger #SVPWSENTCS001
- Wired Temp Sensor -40/+80°C; 3.5M #SVPSENTUE001
- Replacement battery
- Smart Sensors
Specs
• Manufacturer SKU: SVPHWRMOD012
• Model: Smart-Vue Pro Duo
• Manufactured by: Thermo Fisher Scientific
• Unit of Measure: EA
