Part # 2634-81A

Pass-Through; Recirculating HEPA Filtration, 18" W x 18" D x 24" H ID, Standard Wall Mount, 304 Stainless Steel, 120 V

  • Available Certified ISO Grade™ Designs: ISO 6, ISO 7, ISO 8
Stocked ULus Listed UL Leak Rating ISO 6 Icon
Terra Part #: 2634-81A
Manufactured By: Terra Universal
$7,922
Part #: 2634-81A
Usually ships in 1-3 business days

Want it faster ? Read about FasTrak

Only 4 left in stock

Product Details

  • Available Certified ISO Grade™ Designs: ISO 6, ISO 7, ISO 8
  • Recirculating HEPA-filtration version adds another layer of protection against contamination for materials being transferred
  • HEPA filter removes contaminating particles of 0.3 um or larger at 99.99% efficiency
  • Air return slots along bottom interior of the chamber circulate air back through the HEPA filter
  • Blower provides continuous operation when switched on
  • Speed control knob allows adjustment of the blower RPM, increasing the airflow and pressure within the chamber
  • Brushless DC fan motor is clean, quiet and energy-efficient
  • Fool-proof automatic interlock mechanism prevents cross-contamination, is reliable and maintenance-free
  • Upgrade to Smart® models for electronic interlock or motion sensor activation
  • Doors are leak-rated by UL for tight seal to maintain cleanroom pressure gradients
  • Customer must determine if filter system leakage testing is required for their application. If a filter leak test is required, full-seam welded filter housing is optionally available, tested to meet ISO 14644-3

Specs

• Inside Depth: 18"

• Inside Height: 24"

• Inside Width: 18"

• Concealed Interlock: No

• Continuous-Seam Welds: No

• Electropolished: Optional

• HEPA/ULPA Filtration: Yes

• Material: 304 Stainless Steel

• Model: Recirculating HEPA Filtration

• Mounting Position: Standard Wall

• Special Door Configuration: Leak-Rated

• ISO Rated™ Air Cleanliness: ISO 5

• Unit of Measure: EA

• Dimensions, Product: 24.5" W x 18" D x 36" H

• Dimensions, Shipping: 33.25" W x 37.5" D x 46" H

• Electrical Specifications: 120 V

• Marks & Listings: UL, ULC

• Weight, Product: 145 lb

• Weight, Shipping: 175 lb
