Pressure max.: 20 bar
Class designation acc. DIN 12876: I
Identification according to DIN 12876: NFL
Cooling agent: R134a
Cooling agent quantity: 250g
Cooling capacity (20 °C): 400 W
Cooling capacity (10 °C): 370 W
Cooling capacity (0 °C): 320 W
Cooling capacity (-10 °C): 240 W
Cooling capacity (-20 °C): 130 W
Operating temperature min.: -20 °C
Working temperature min.: -20 °C
Working temperature max.: room temp
Temperature stability DIN 12876 [±K]: 0.05
Temperature display: yes
Temperature control: PT 100
Working temperature sensor: PT 100
Working temperature display: LED
Display resolution : 0.1 ±°C
Display for operation with ext. Sensor: yes
Warning function optical/acoustic/excess temp: yes/yes/yes
Warning function insufficient temperature: no
Sub-level protection: yes
Bath volume min/max: 1.4 l/4.0 l
Pump type: Pressure- / suction pump
Pump capacity adjustable: yes
Pump pressure max. (0 liters discharge flow): 0.3 bar
Pressure pump (suction side) (0-liter flow): 0.2 bar
Pump pressure max. (0 bar backpressure): 18 l/min
Calibration option : yes
Technical data complies with DIN EN 60529: IP 21
Permissible ON time: 100%
Permissible ambient temperature: 5-32°C
Permissible relative humidity: 80%
RS 232 and USB: yes
For use with C 6000 Calorimeters
Includes: feed hopper and bleed valve
4 liter bath reservoir allows up to 2.5 L of thermofluid in external cooling circle without refilling
Powerful 400 W cooling capacity cools applications up to -20 °C
Indirect continuous adjustment of max pressure and flow rate with speed-controlled PEEK PUMP
Measures and controls temperature directly in working medium with Pt100 temperature sensor connection
WiCo wireless controller operates RC2 independent of device position
10 programmable temperature ramps with 10 steps
Easy to open front hood
