Learn More: RXPert Balance System Specs
Labconco RXPert Single Filtered Balance Systems
| Nominal Width (A) | 2 ft. | 3 ft. | 4 ft. |
|---|---|---|---|
| Weight | 205 lbs. (93 kg) | 258 lbs. (117 kg) | 311 lbs. (141 kg) |
| Dimensions (W x D x H) | 24.0" x 29.0" x 41.2" (609.6 x 736.6 x 1046.5 mm) | 36.0" x 29.0" x 41.2" (914.4 x 736.6 x 1046.5 mm) | 48.0" x 29.0" x 41.2" (1219.2 x 736.6 x 1046.5 mm) |
| Electrical | 115V, 60Hz | 115V, 60Hz | 115V, 60Hz |
| Exhaust Volume (CFM) | 85 CFM at 60 FPM | 130 CFM at 60 FPM | 175 CFM at 60 FPM |
| 115 CFM at 80 FPM | 175 CFM at 80 FPM | 235 CFM at 80 FPM | |
| Lighting | Fluorescent | Fluorescent | Fluorescent |
| Filter System | HEPA (bag-in/bag-out) | HEPA (bag-in/bag-out) | HEPA (bag-in/bag-out) |
| Sash Opening (B) | 21.6" (549 mm) | 33.6" (853 mm) | 45.6" (1158 mm) |
| Conformance | ANSI Z9.5, CAN/CSA C22.2, Modified ASHRAE 110, SEFA 1, UL 61010 | ANSI Z9.5, CAN/CSA C22.2, Modified ASHRAE 110, SEFA 1, UL 61010 | ANSI Z9.5, CAN/CSA C22.2, Modified ASHRAE 110, SEFA 1, UL 61010 |
| Warranty | 2 years from date of shipment or 1 year from date of installation | 2 years from date of shipment or 1 year from date of installation | 2 years from date of shipment or 1 year from date of installation |
| Noise Levels and Exhaust at Varying Face Velocities | ||||||
|---|---|---|---|---|---|---|
| Nominal Width | 100 FPM Face Velocity | 80 FPM Face Velocity | 60 FPM Face Velocity | |||
| Exhaust (CFM) | db(A) | Exhaust (CFM) | db(A) | Exhaust (CFM) | db(A) | |
| 2 ft. | 145 | 53-58 | 115 | 50-55 | 85 | 48-53 |
| 3 ft. | 220 | 58-61 | 175 | 53-58 | 130 | 48-53 |
| 4 ft. | 290 | 62-66 | 235 | 58-61 | 175 | 49-54 |
