Select Product
Capacity

Maximum Speed

Maximum Viscosity

Plug Type

Model

Manufacturer SKU

Maximum Torque

Terra Part # Price Ships in
20 L 2200 rpm 10000 mPas EU Plug OS-20L IPS2050-20-E 40Ncm 6927-31 80203 $815 3-5 Days 2
Ships Free Free shipping in contiguous USA
20 L 2200 rpm 10000 mPas US Plug OS-20L IPS2050-20 40Ncm 6927-30 80194 $815 3-5 Days 3
Ships Free Free shipping in contiguous USA
40 L 2200 rpm 50000 mPas EU Plug OS-40L IPS2050-40-E 60Ncm 6927-33 80205 $1,280 3-5 Days 4
Ships Free Free shipping in contiguous USA
40 L 2200 rpm 50000 mPas US Plug OS-40L IPS2050-40 60Ncm 6927-32 80204 $1,280 3-5 Days 5
Ships Free Free shipping in contiguous USA
Capacity
Maximum Speed
Maximum Viscosity
Plug Type
Model
Manufacturer SKU
Maximum Torque
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Select a product line for product summary
Product Details
Product Details
  • High torque 20L and 40L Overhead Stirrers provide smooth mixing of low and medium viscosity samples
  • Compact and quiet models with an easy-to-read LCD control panel provide digital accuracy and monitors speed and run times
  • Feed-through chuck holds accessories firmly in place without the need for tools
  • Additional propellers and paddles available
  • •  Includes: stand assembly with mounting hardware, and a 4-arm stainless steel propeller #IPS2050-P-S4
  • Stand compatible with a variety of vessels up to 24” high
  • Features a key less chuck, protective chuck cover, stir blade, stand, extension and motor all included with model
  • Sensors protect overhead stirrers from damage by shutting down in event of obstruction or high viscosity
  • Brushless DC motor
  • Specifications:
  • Speed Range: 30-2200 rpm
  • Maximum Torque: 40Ncm (20L); 60Ncm (40L)
  • Maximum Viscosity: 10000mPas (20L); 50000mPas (40L)
  • Chuck Diameter Range: 0.5-10 mm
  • Protection Mode: IP42
  • Ambient Operating Range: 5-40°C

Shaft Length: [xxx] mm

Immersion Depth: [xxx] mm

Unit of Measure: of 1
