High-throughput ISOPure 96 Automated System 115V compatible with popular magnetic bead kits
Processes up to 96 samples in deep-well plates for sample volumes from 50μL - 1000μL
• Features: 7" color touchscreen, 8-position carousel with two heating blocks, and includes mouse and flash drive
Improves efficiency and reproducibility in isolating DNA, RNA and other target molecules from biological samples
Completes purification process in 10 to 60 minutes (depends on type of reagent used and protocol complexity)
Step settings: tip comb loading and unloading, mixing (programmable protocol parameters), temperature control for lysis and elution, bead collection and release (ISOPure software and general settings provide cleaner extractions and consistent yields)
Plate positions: 8
Communication ports: USB, LAN, & PC
Cooling fan inside chamber maintains ambient temperature
Programming control via PC or 7" color touchscreen (for on-board programming)
Lysis and elution temperature range: Ambient +5°C to 120°C
Magnetic bead recovery rate: >95%
Mixing speed: Variable 10 levels
Program Memory: 100 programs
Color touchscreen displays parameters and program status
Internal lighting: LED
Contamination control: UV lamp (3W, 253.7nm UVC wavelength) in inner chamber eliminates DNA and RNA contamination
Protocol optimization on specific magnetic bead-based kits and applications available (contact us for details)
Available consumables: 96 deep-well plates and tip comb
ISOPure 96 model features two heating blocks on the 8-plate carousel and a precise temperature range of + 5°C to 120°C ideal in Lysis and elution steps
UV Sterilization
ISOPure 96 features a UV lamp inside the chamber to effectively eliminate DNA and RNA contaminants; ideal for PCR assays
