Incubator; Reach In, 29 cu. ft., Large Capacity, Thermo Fisher, 120 V

• Leveling feet provides stability and added safety
• Airflow prevents product desiccation
• Easy to configure and use; audible/visual alarm and alarm silence; remote alarm contacts and available data outputs connects to in-house monitor/alarm to track chamber conditions (helps with meeting internal and regulatory documentation requirements)
• Data outputs help meet internal and regulatory documentation requirements
• Built-in features eliminate need for expensive add-ons
• Interior Dimensions (W x D x H): 31 x 27 x 60 in. (787 x 686 x 1524 mm)
• Exterior Dimensions (W x L x H): 38 x 33 x 80 in. (965 x 838 x 2032 mm)
• Available accessories, built-in gas guards, factory-installed data outputs, 2-stage gas regulators and shelves
• Humidity System: 15.1L pan
• Relative Humidity Range: Off, med. >80%, high >90%
• Temperature Control: ± 0.1°C
• Temperature Uniformity: ± 0.3°C at 37°C
• Temperature Range: + 5°C above ambient to 60°C

Cell Roll System

The optional cell roll system (shown installed within the incubator chamber) allows extensive production of monolayer cell cultures in standard roller culture vessels.

• Improves oxygenation and exposure of the cells to the media growth area
• Increases culture yields by the uniform temperature control and cellroller system's continuous, gentle rotation
• Accommodates a cell roller up to 7 decks high with 5 positions per deck—maximum total of 35 positions or bottles.
• Requires three tier models 4862 or 4868 to achieve maximum capacity:
• three tier cell roller base (15 positions)
• four add-on tiers (20 positions)
• and a reinforced floor/ramp to achieve

Directed Horizontal Laminar Airflow System

• Promotes ideal growth environment by releasing positive pressure feed plenum on the left side of the chamber and a negative pressure return plenum on the right side
• The combination of airflow directs air across the surface of each solid shelf
• Each shelf receives a consistent flow of conditioned air when filled with samples or equipment
• Chamber contents will not block feed plenum
• Minimizes risk of product desiccation and loss
• The directed airflow saves time and money by minimizing the risk of product desiccation and loss

Applications for Heratherm Advanced Protocol Security Microbiological Incubators

• Clinical and Medical labs: microbiological diagnostic testing
• Pharmaceutical: quality control testing, safety and testing efficacy of manufactured products
• Food: screening for bacterial contamination
• Research and biotech labs: bacterial growth, gene expression studies, production of recombinant proteins
