Available Certified ISO Grade Designs: ISO 5, ISO 6, ISO 7, ISO 8
Available in top-side replaceable and room-side replaceable configurations
90 fpm airflow up to 1.0" wg static pressure levels
Electronically commutated (EC) brushless motor provides a quieter sound level than most 2' x 4' fan filter units at 52.3 dBA
Backward inclined blower wheel for efficiency in airflow performance
Finger guard protected inlet to protect users and the equipment
Uses HEPA filter, 99.9% efficient at 0.3 micron particle size
Aluminum or 304 Stainless Steel construction
Walkable plenum of up to 250 lbs max for easier maintenance access (top-side replaceable unit only)
Meets IEST recommended practices
Specifications
• Unit of Measure: of 1
HEPA Filters Prevent Infection
Watch Terra's Portable HEPA Filtration System Video
HEPA filters capture and mitigate airborne particles that can cause infections.HEPA Filters Prevent InfectionHEPA and ULPA filters capture and mitigate airborne particles, as well as pathogens including Rhinoviruses, Influenza, SARS-CoV-2, and RSV. Filters also combat aerosolized bacteria like C. Difficile, a prevalent cause of hospital-acquired infections.
Terra's in stock portable HEPA filtration systems provide high quality and medical grade air filtration for your ambient environment.Watch Terra's Portable HEPA Filtration System VideoThe mobile/ self contained filtration system converts to any room to a negative pressure isolation room which then makes it well suited for medical clinics, schools, waiting rooms and other confined areas.
HEPA and ULPA filters help capture many bacteria, viruses (COVID-19), and mold spores that contribute to a host of infections for both humans and plant/animal tissue cultures
Airflow Uniformity Improves Laminar Flow
Non-uniform air speeds produce turbulence that can recirculate particles into the air stream. Unique WhisperFlow® FFU baffling system and anodized diffuser plate promotes uniform laminar airflow to minimize turbulence and effectively carry away contaminating particles.
Wide Selection of Global Shipping Options
Terra offers a broad range of global shipping services including door-to-door and white glove delivery. Each product is safely packaged in a heat-treated wooden crate that meets international shipping standards.
Catalog of CE-Marked Products
Terra offers over 1,700 CE-marked products configured for international voltage requirements
Products Compliant With Your ISO Rating
High-capacity, durable, ISO-compliant system rated for thousands of operating hours.
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
Energy-Efficient Lighting
Energy-efficient LED lighting panels and strips help to lower electrical costs and minimize heat build-up in temperature-controlled environments.
Power Distribution Modules for Cleanroom FFUs and Lights
UL-listed power distribution modules include all breakers, transformers and other electrical components for FFU/light connections; allows fast addition or relocation of FFUs or lights without the need for rewiring.
Ionizing Bar; 22"L, with Installation Kit, for 24 x 24 Fan/Filter Unit
Ionizing bar, mounted to Fan/Filter Unit, provides a balanced stream of ions to the work area below to neutralize static charge and prevent electro-static discharge; 22" bar shown installed on 2' x 2' FFU.
Night Service Saves Energy, Extends Filter Life!
Night service switch, shown mounted on Modular Hardwall Cleanroom panel, puts FFUs in low-energy mode during off-hours; saves 25% of fan operating costs and extends filter life.
Filter Replacement Alarm
The filter replacement alarm monitors filter backpressure and issues an alarm when filter needs replaced (requires selection of fan filter unit with challenge port, order separately).
Cord Adapter, MIN4 PL to 16AWG Power Cord for Terra Fan/Filter Unit
Four-pin power cord adapter for fan/filter unit allows connection to standard 120VAC/60Hz power receptacle.
FFU Mounting Frame; Stainless Steel
Stainless steel Fan Filter Unit (FFU) mounting frame supports FFU on drywall or other rigid ceiling material, viewed from above ceiling panel (FFU not included).
Fan Filter Unit Control System
Provides room-by-room monitoring and control of Smart WhisperFlow FFUs to maintain target pressure differentials for ISO classification; temperature, humidity and particle monitoring and data logging, as well as dynamic fan set-point control, also available.
Filter Covers Allow Ceiling Wash-Down
Ceiling panel covers allow wash-down and sterilization of cleanroom walls and ceilings without damage to filter medium; requires BioSafe glass or stainless steel wall panels, which stand up to biocides.
Challenge Port for Fan Filter Unit
Challenge port for Fan/Filter Units simplifies filter leak testing and connection of Filter Backpressure Alarm (shown with optional pressure gauge; must be ordered with FFU).
Safely Mount FFU’s Above Floor for Horizontal Laminar Airflow
The portable FFU base stand can be easily positioned to supply Class 100 horizontal laminar flow into a room or enclosure. It can also be positioned next to sensitive equipment/materials that are mounted close to the floor.
Purchase replacement filters ahead of time to prevent costly operational interruptions and avoid damage to fan blowers caused by excessive backpressure from long overdue filter replacements.
