Summary

  • Compact 120V model with DualSpin 2-in-1 hybrid rotor and 4 customizable programs
  • Interchangeable fixed angle and swinging buckets
  • Max RCF: 3114 x G (fixed angle); 3,490 x G (swinging bucket)
  • Includes: Medifuge, DualSpin rotor,  8 each of Fixed angle and swinging buckets and spaces
  • Lid lock and lid emergency release, view port for speed calibration, steel armored ring
  • Acceleration/Deceleration Rates (at standard curve): 24/37 seconds (fixed angle) or 24/31 seconds (swinging bucket)
  • Time Setting 1-99 minutes, in increments of 1 minute; HOLD
  • Temperature Range 2°C to 40°C
  • Acceleration Profile 1 (standard)
  • Deceleration Profiles 3 (standard, soft, brake-off) for optimum separation
  • Noise Level <56 dBA (swinging bucket)
  • Standards IEC 61010-1, IEC 61010-2-020, IEC 61010-2-101,
  • EN 61326-1, EN ISO 13485
  • Certifications UL, CE, RoHS, CSA, IVD, FDA class 1
  • Complete package: DualSpin Rotor #75008810 (factory installed), fixed angle and swing out buckets, rotor locking nut. spacers hex key tool, instruction manual and CD
  • Induction drive
  • Control System Microprocessor
  • User Interface Large, brightly-lit LED display
  • Large, bright LED display
  • One-click lid closure
  • Applications: Clinical and life science separations: sample separations (cell pelleting), serum preparation, urinalysis, clinical chemistry analysis, hematology analysis, serum preparation

Specifications

Temperature Control: Standard

Maximum Speed: 4900 rpm

Controls: Digital

Manufactured by: Thermo Fisher

Model: Medifuge

Manufacturer SKU: 75008801

Type: Centrifuge

Unit of Measure: EA

Electrical Specifications: 120 V, 60 Hz

Weight, Product: 34.1 Lbs

Dimensions, Product: 12.79"W x 17.72"D x 9.45"H

Weight, Shipping: 46 Lbs

Dimensions, Shipping: 20"W x 25"D x 10"H

Package Type: Box
