SAMPLES
Sample Capacity: 16 samples in parallel;
Processes different starting materials with identical pipetting protocols
Sample Handling: Single providing of tips, samples and Elution Tube into Sample Tray; Insertion of pre-filled Reagent Strips and/or Plates into Sample Tray
Sample Amount: Up to 2 ml or up to 50 mg
Elution: Separate container with cover
Elution Volumes: 50-500 μl
SYSTEM PARAMETERS
Extraction Time: Minimum 40 minutes (depending on starting material)
Drive: 5 quiet long-life servomotors
Instrument Controls: Stand-alone (HID-Pro 320 with 5.7" color touchscreen)
Maintenance: Maintenance-free with assignment of wearless high grade steel pistons
Cleaning: Easy to access and clean system components via front door
Temperature Control: Heated position up to 50 °C inside the sample
Operation Principle: Magnetic and paramagnetic particle adsorption; binds nucleic acids onto beads for extraction

Adsorption of isolated material onto magnetic or paramagnetic particles

Transfers eluates automatically into Elution Tubes with caps

Portable HID-Pro 320 interface for ease and convenience

USB Interface

Optional: UV Lamp , Priming Station, Sample Tray, Adapter for 4 Reagent Strips and Piercing Tool

16 samples in parallel with elution volumes from 50-500 μl

Fast extraction of genomic DNA, viral and bacterial nucleic acids

Includes HID-Pro 320, Priming Station and Sample Tray for up to 2 Reagent Plates

Fully automated magnetic particle separation process; highly reproducible

• Type: Automated DNA Extractor

• Model: InnuPure C16 touch

• Manufactured by: Analytik Jena

• Sample Type: PCR Strips

• Priming Trough Included: Yes

• Configuration: Multi Channel

• Manufacturer SKU: 845-00020-2

• Capacity: [xxx]

• Unit of Measure: EA

• Electrical Specifications: 110/230 V

• Weight, Product: 67 lb

• Dimensions, Product: 16" W x 21" D x 22" H

• Weight, Shipping: 85 lb

• Dimensions, Shipping: 16" W x 21" D x 22" H

• Package Type: Box

Manuals & Resources

Liquid Handlers & Robotics

Features and Benefits

Robust Design with Improved Closure

The redesigned spring-loaded door keeps the InnuPure C16 closed tight for optimum performance during operation of the unit.

10" Touchscreen for Stand-Alone Operation

The integrated touchscreen streamlines the choosing of liquid handling protocols and serves high-throughput analytical labs with the barcode reading feature.

Ready-to-Use Extraction Kits

InnuPure C16 supports sample preparation with available DNA and RNA Isolation Kits in prefilled, sealed strips and plates

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Basis	Magnetic or paramagnetic particles
Duration of extraction	Externe Lysis: < 45 min (ohne Lyse) Interne Lyse: < 75 min (inkl. Lyse)
Ø Yield	Depending on type and amount of sample Tissue (20 mg): up to 50 μg Whole blood samples (200 μl): up to 10 μg Plant (100 mg): up to 60 μg
Elution volume	20 μl up to 500 μl (in steps of 10 μl)
Field of application	DNA and RNA extraction
Number of samples	Up to 16 samples in parallel, incl. single sample preparation
Sample amount	Depending on the type of sample Up to 10 ml or 180 mg respectively
Tempering	Up to 70 °C inside the sample Support of lysis, drying and elution
Control	Stand-alone control
Display	10“ tablet PC, color, touch, WIN 8.1
Features	Sample-based wizard Automatic pipetting of chosen elution volume Automatic transfer of eluates into storage tubes with lid Pre-installed extraction and decontamination protocols Video sequences and display of residual time for ideal overview of the run User management with 3 user levels
Pipetting head / Channels	Dosing unit with 16 channels
Tips	1 ml tip with aerosol filter
Working volume	Up to 1000 μl
Functions	Pipetting and piercing function of the sealed reagent plastic
Cleaning / Decontamination	Big front door for easy access and wipe decontamination of the sample room Optional: UV lamp for decontamination between two runs by 254 nm UV light
Kits and Reagents	Ready-to-use kits for DNA and RNA extraction
Additional	Priming Station and Sample Tray
Interface	Tablet: USB for data transfer, barcode reader
Noise emission	Max. 55 dB

Automated DNA Extractor; InnuPure C16 touch, Analytik Jena, 110/230 V
